Color Coded PCB Test Points. Miniature THM Test Point.

1 - 10 of 10 | Results Per Page | View | Unit of Measure

1

Request Information Compare Items

Item #	Item Name	Mounting Hole Diameter	Mounting Center Length	Mounting Center Width	Length

5000	N/A Miniature Style Test Point Terminal - Red	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
5001	N/A Miniature Style Test Point Terminal - Black	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
5002	N/A Miniature Style Test Point Terminal - White	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
5003	N/A Miniature Style Test Point Terminal - Orange	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
5004	N/A Miniature Style Test Point Terminal - Yellow	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
5115	N/A Miniature Style Test Point Terminal - Brown	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
5116	N/A Miniature Style Test Point Terminal - Green	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
5117	N/A Miniature Style Test Point Terminal - Blue	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
5118	N/A Miniature Style Test Point Terminal - Gray	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
5119	N/A Miniature Style Test Point Terminal - Purple	N/A 0.040 in1.02 mm	N/A 0.100 in2.54 mm	N/A 0.100 in2.54 mm	N/A 0.010 in0.25 mm
