Battery Contacts for Molded Cases On Keystone Electronics Corp.

COMPANY HEADER

1 - 25 of 51 | Results Per Page | View | Unit of Measure

1 2 3

Request Information Compare Items

Item #	Item Name	Material Thickness	Material	Material Plating

204	N/A Snap-On Battery Contact	N/A 0.010 in0.25 mm	N/A Spring Steel	N/A Nickel
238	N/A Snap-On Battery Contact	N/A 0.010 in0.25 mm	N/A Spring Steel	N/A Nickel
202	N/A Snap-On Battery Contact	N/A 0.010 in0.25 mm	N/A Spring Steel	N/A Nickel
294	N/A Snap-On Battery Contact	N/A 0.010 in0.25 mm	N/A Spring Steel	N/A Nickel
295	N/A Snap-On Battery Contact	N/A 0.010 in0.25 mm	N/A Spring Steel	N/A Nickel
296	N/A Snap-On Battery Contact	N/A 0.010 in0.25 mm	N/A Spring Steel	N/A Nickel
209	N/A Snap-On Battery Contact	N/A 0.012 in0.30 mm	N/A Spring Steel	N/A Nickel
228	N/A Snap-On Battery Contact	N/A 0.010 in0.25 mm	N/A Spring Steel	N/A Nickel
288	N/A Snap-On Battery Contact	N/A 0.012 in0.30 mm	N/A Spring Steel	N/A Nickel
292	N/A Snap-On Battery Contact	N/A 0.010 in0.25 mm	N/A Spring Steel	N/A Nickel
210	N/A Snap-On Battery Contact	N/A 0.010 in0.25 mm	N/A Spring Steel	N/A Nickel
291	N/A Snap-On Battery Contact	N/A 0.012 in0.30 mm	N/A Spring Steel	N/A Nickel
290	N/A Snap-On Battery Contact	N/A 0.012 in0.30 mm	N/A Spring Steel	N/A Nickel
5205	N/A Slide-In Mount Battery Contact	N/A 0.012 in0.30 mm	N/A Spring Steel	N/A Nickel
5206	N/A Slide-In Mount Battery Contact	N/A 0.012 in0.30 mm	N/A Spring Steel	N/A Nickel
5209	N/A Slide-In Mount Battery Contact	N/A 0.012 in0.30 mm	N/A Phosphor Bronze	N/A Nickel
5208	N/A Slide-In Mount Battery Contact	N/A 0.012 in0.30 mm	N/A Phosphor Bronze	N/A Nickel
230-1	N/A Slide-In PC Mount Battery Contact	N/A 0.008 in0.20 mm	N/A Spring Steel	N/A Nickel
1021-1	N/A Slide-In PC Mount Battery Contact	N/A 0.012 in0.30 mm	N/A Phosphor Bronze	N/A Tin-Nickel
1017-1	N/A Slide-In PC Mount Battery Contact	N/A 0.012 in0.30 mm	N/A Phosphor Bronze	N/A Tin-Nickel
109-2	N/A Slide-In PC Mount Battery Contact	N/A 0.012 in0.30 mm	N/A Spring Steel	N/A Nickel
109-3	N/A Slide-In PC Mount Battery Contact	N/A 0.012 in0.30 mm	N/A Spring Steel	N/A Nickel
108-2	N/A Slide-In PC Mount Battery Contact	N/A 0.012 in0.30 mm	N/A Stainless Steel	N/A Tin-Nickel
5203	N/A Spring & Button Battery Contact	N/A 0.020 in0.51 mm	N/A Spring Steel	N/A Nickel
5225	N/A Spring & Button Battery Contact	N/A 0.020 in0.51 mm	N/A Spring Steel	N/A Nickel

1 - 25 of 51 | Results Per Page | View | Unit of Measure

1 2 3

Item #

Item Name

Material Thickness

Material

Material Plating
