Item # 4590
Item # 4590, Sockets for T0-5 & TO-100
4590
Sockets for T0-5 & TO-100
Request Information
Email This Page
Download PDF
Download PDF
Printable Page
/Asset/a1081.jpg
/Asset/a1081.jpg
Close Window
Fully molded compact construction. Speeds transistor assembly. Incorporates ultra high quality, closed entry, sleeve type contacts. Accepts 0.016 (0.41) to 0.020 (0.51) diameter leads or 0.010 (0.25) x 0.018 (0.46) rectangular transistor leads.
Unit of Measure
Imperial
Metric
Both
Specifications
|
Material
Specifications
Lead Diameter
N/A
0.016 in
0.41 mm
Rectangular Transistor Lead Diameter
N/A
0.010 x 0.018 in
0.25 x 0.46 mm
Certification
N/A
ISO 9001
RoHS Compliant
Material
Insulator Material
N/A
Glass Filled Polyester
Material Standards
N/A
UL Rated 94V-0
Contact Pin Material
N/A
Brass
Contact Pin Finish
N/A
Tin Plate
Contact Spring Material
N/A
Beryllium
Copper
Contact Spring Finish
N/A
0.000030 minimum Gold Plate
