Choice of single or dual collector solder tabs

Features an all-in-one mounting plate and solder tabs, providing complete electrical isolation of the solder tab connections.
Rated 5 Amps DC continuous and 15 Amps DC Intermittent
Unit of Measure

Specifications

Rated DC Current

 N/A 5 A

DC Intermittent Current

 N/A 15 A

Material Standards

 N/A UL Rated 94V-0

Certification

 N/A ISO 9001 RoHS Compliant

Material

Base Material

 N/A Glass Filled Polyester

Contact Material

 N/A Brass

Contact Finish

 N/A Tin Plate

Collector Plate Material

 N/A Brass

Collector Plate Finish

 N/A Tin Plate

Note

N/A Less transistor lead-in insulating shoulders with tab "A" only
