  • Available in Thru Hole Mount (THM) or Surface Mount (SMT) configurations
  • SMT solder tail with "flow-hole" design for increased joint strength
  • THM legs maintain relative position during and after soldering
  • Ideally suited for High Density packaging
  • Reliable spring tension assures low contact resistance
  • Retains battery securely to withstand shock and vibration
  • Solder tail located outside of retainer body which facilitates visual inspection of the solder joints
Unit of Measure

Specifications

Battery Reference

 N/A ML414

Material Thickness

 N/A 0.006 in0.15 mm

Material

 N/A Phosphor Bronze

Plating

 N/A Tin-Nickel

Mount Type

 N/A Thru Hole

Certification

 N/A ISO 9001 RoHS Compliant

Package Type

 N/A Each

Note

N/A Economical and reliable SMT and THM coin cell retainers specifically designed for miniature electronic applications with limited board space.
