Unit of Measure

Specifications

Battery Reference

 N/A CL2025 CR2032 CR2016 DL2020

Base Material

 N/A PBT

Material Thickness

 N/A 0.012 in0.30 mm

Contact Material

 N/A Spring Steel

Contact Plating

 N/A Tin-Nickel

Operating Temperature Range

 N/A -60 to +293 ºF-50 to +145 ºC

Certification

 N/A UL Rated 94V-0 ISO 9001 RoHS Compliant

Advantage

N/A

  • Accepts all major manufacturers' 20 mm diameter batteries
  • Molded notch prevents improper insertion of 2032 size cells
  • Retains cells securely, withstands shock and vibration
  • Polarity clearly marked
  • Mounts securely for wave soldering
  • Temperature range: -60 ºF to +293 ºF (-50 ºC to +145 ºC)
