Unit of Measure

Specifications

Battery Reference

 N/A BR2025 CR2032

Base Material

 N/A Nylon

Material Thickness

 N/A 0.016 in0.40 mm

Contact Material

 N/A Phosphor Bronze

Contact Plating

 N/A Tin

Certification

 N/A UL Rated 94V-0 ISO 9001 RoHS Compliant

Advantage

N/A

  • Battery "Pop-in" from top for compact applications
  • Finger pressure against leaver will release battery
  • No tools required for battery changes
