Unit of Measure

Specifications

Battery Reference

 N/A BR2012 CL2025 CR2032 CR2016 DL2020

Base Material

 N/A PBT

Material Thickness

 N/A 0.016 in0.40 mm

Contact Material

 N/A Spring Steel

Contact Plating

 N/A Tin-Nickel

Operating Temperature Range

 N/A -60 to +293 ºF-50 to +145 ºC

Certification

 N/A UL Rated 94V-0 ISO 9001 RoHS Compliant

Advantage

N/A

  • Polarized holder
  • Mounts securely for wave soldering
  • Reliable spring tension assures low contact resistance
  • Retains 20mm batteries securely to withstand shock and vibration
  • Temperature range -60 ºF to +293 ºF (-50 ºC to +145 ºC)
