Unit of Measure

Specifications

Number of Cells

 N/A 1

Battery Reference

 N/A BR1612, CR1616, CL1620, CR1625, BR1632

Operating Temperature Range

 N/A -60 to +293 º F-50 to +145 º C

Certification

 N/A ISO 9001 RoHS Compliant

Package Type

 N/A Each

Material

Base Material

 N/A Polybutylene Terephthalate (PBT)

Rating

 N/A UL Rated 94V-0

Material Thickness

 N/A 0.010 in0.25 mm

Contact Material

 N/A Steel

Contact Plating

 N/A Tin-Nickel

Advantage

N/A Design Advantages

  • Reliable spring tension assures low contact resistance
  • Retains battery securely to withstand shock and vibration
  • Base material UL Rated 94V-0. Impervious to most industrial solvents
  • Operating temperature range: -60 ºF to +293 ºF (-50 ºC to +145 ºC)

Application

N/A Ideally Suited For

  • Computer memory, power transfer and back-up systems
  • Video and telecommunications power back-up
  • Microprocessors and Microcomputer memory hold (desktop and laptop applications)
  • Industrial and commercial security and alarm systems
  • PC/104 application
